Baifan Solar · Division 01
Street lighting that does not need the grid.
Integrated and split luminaires, solar flood lights and SKD kits. Sized from the road, tested before packing, and shipped with the transport documents your forwarder will ask for.
VIP All-in-One
All-in-One Solar Street Light
Integrated lamp, panel and battery. Two models: the 936 and the W2000 aircraft-style body.
View
VIP Flood
Solar Flood and Area Light
Wall or pole flood lighting from 281 to 550 LEDs, with a twin-head option.
View
VIP Street
Split Solar Street Light
Lamp head, separate panel and arm, W3000 to W6000. 6 m pole optional.
View
VIP Heads & Kits
Solar Lamp Heads, Portable Lights and Kits
Universal heads, portable lanterns and Bluetooth lamps for assemblers and retrofit.
ViewSelection
Start with the road, not the wattage.
This table is the shortcut. The full method, including the arithmetic for battery and array sizing, is in the sizing guide.
| Carriageway | Mounting height | Typical model | Spacing | Target illuminance |
|---|---|---|---|---|
| 3–5 m village road | 4–5 m | BF-VIP-936 | 15–20 m | 3–5 lux |
| 5–7 m access road | 6–8 m | BF-VIP-W3000 | 24–32 m | 5–10 lux |
| 7–9 m collector | 8–9 m | BF-VIP-W4000 | 30–36 m | 8–12 lux |
| 9–12 m arterial | 9–12 m | BF-VIP-W6000 | 36–48 m | 15–25 lux |
| Yard, gate or billboard | 4–8 m | BF-VIP-1000W550 | 40–60 m throw | Area lighting |
Indicative only. Junction geometry, tree cover and crime risk all move the answer.
For assemblers
Ship the parts. Keep the assembly margin.
If you assemble in-country, finished luminaires are the wrong unit economics. We ship matched SKD kits with tested electronics, neutral packaging and a spare-part ratio agreed per order.
- Matched BOM and wiring diagram per kit
- 100 percent functional test before packing
- Neutral cartons, your label on request
Tell us the road. We will size the pole.
Road width, length, mounting height and the lighting class your authority expects. That is enough to come back with a layout.
